Casa /Produtos/Gerador diesel silencioso/Super Silence ATS Remote 50Hz 60Hz 1200KW 1340KW Diesel Generator 1500KVA 1675KVA 1875KVA 2063KW Power Generator for Backup Power

Super Silence ATS Remote 50Hz 60Hz 1200KW 1340KW Diesel Generator 1500KVA 1675KVA 1875KVA 2063KW Power Generator for Backup Power

1
MOQ
USD+2547.22
preço
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Classificação de potência: 1.340 kW
Potência nominal: 1675kva
Sistema de controle: Digital
Capacidade do tanque: 3082L
Fase: 3
Freqüência: 50/60Hz
RPM: 1500/1800
Tipo: Silencioso/Aberto
Alternador: China Stamford, Stamford original, Leroy Somer
Pacote: Madeira compensada, embalagem do filme plástico
Destacar:

Cummins diesel generator with ATS remote

,

1200KW diesel generator for backup power

,

50Hz 60Hz power generator with warranty
Informação básica
Lugar de origem: China
Marca: Cummin
Certificação: CE
Número do modelo: KTA50-G15X
Condições de Pagamento e Envio
Detalhes da embalagem: 560cm*215cm*225cm
Tempo de entrega: 20-30 dias úteis
Termos de pagamento: L/C, T/T
Descrição de produto
Super Silence Diesel Generator with ATS Remote Control
High-performance soundproof power generator sets providing super silent operation and reliable backup power solutions for industrial and commercial applications. Available in 50Hz/60Hz configurations with power ratings from 1200KW to 2063KW (1500KVA to 2063KVA).
Product Overview
Silent Diesel Generator delivering reliable power with high-quality Cummin diesel engine. Available in both silent and open type configurations with customizable power options.
Bobig Doosan Diesel Generator unitBobig generator internal componentsDoosan Generator Assembly processGenerator Control Panel interface
Technical Specifications
ParameterPrime PowerStandby Power
Rated Power (kVA)16751843
Power Rating (kW)13401474
Frequency (Hz)50
Engine ModelKTA50-G15X
Engine Speed (RPM)1500
Phase3
Power Factor (PF)0.8
Control SystemDigital
Rated Voltage (V)400/230 (Customizable)
Fuel Tank Operating Time≥ 8 hours @ 75% load
PRP (Prime Rated Power): Available for unlimited annual hours in variable load applications according to GB/T2820-97 standards. Includes 10% overload capability for 1 hour within 12-hour operation.
ESP (Emergency Standby Power): Applicable for supplying emergency power during utility interruptions. No overload capability available at this rating.
Generator dimensions diagram and technical specifications
Dimensions and Weight
ModelBC1843 (Open Type)BC1843S (Silent Type)
Length (L) mm56006100
Width (W) mm21502250
Height (H) mm22503050
Tank Capacity (L)30823082
Engine Specifications
Engine Model & ManufacturerKTA50-G15X
Number of Cylinders16
Cylinder ArrangementIn-line
CycleFour Stroke
AspirationTurbocharged, LTA
Bore x Stroke159 x 159 mm
Displacement50.3 L
Compression Ratio13.9:1
Prime Power/Speed1491 kW/1500 rpm
Standby Power/Speed1657 kW/1500 rpm
Fuel System PT
Cooling SystemForce Water Cooling Cycle
Frequency Droop≤ 5%
Lubrication System Capacity47.0 L
Coolant Capacity (Engine Only)37.0 L
Fuel Consumption @ 100% Load195 g/kWh @1500 rpm
Starter MotorDC 24V
Charge AlternatorDC 24V
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-454D
Alternator Rated Power1340kw/1675kva
Rated Voltage (V)230v/400v
Rated Frequency50hz
Connecting Type3 Phase and 4 W
Number of Bearings1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation ClassH class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%～+20%
Manufacturer Profile
Established in 2004, Fujian Bobig Electric Machinery Co., Ltd. specializes in technological research, production and sales of electrical machinery. Operating from a 10,000 square meter facility with 160 employees including 20 technicians.
Product Range
Comprehensive product line including air-cooled gasoline generators, air-cooled diesel generators, air-cooled welding & generating sets, and water-cooled diesel generator sets. Known for reliable quality in small air-cooled brushless generators and welding sets.
Quality Commitment
Adhering to "Quality, Creation, Service and Development" principles with continuous technology updates and quality improvements. Advanced testing equipment includes CAD systems, automated assembly equipment, and digital testing systems. ISO9000 Quality System Certified.
Bobig Electric Machinery production line and assembly processBobig Electric Machinery quality control inspectionBobig Electric Machinery manufacturing facilityBobig Electric Machinery facility overviewGenerator packing condition and preparationBobig Electric Machinery manufacturing processBobig Electric Machinery trade show participationBobig Electric Machinery international trade exhibition
After Sales Services
  • Customized manufacturing solutions
  • Comprehensive quality control
  • International logistics management
  • Documentation and certification support
  • Trade support services
  • After-sales technical assistance
  • Customer training programs
  • Market support initiatives
  • Technical collaboration opportunities
Frequently Asked Questions
Are you a manufacturer or trading company?
We are a professional manufacturer with our own factory in Fujian, China. We welcome facility visits to observe our quality control processes firsthand.
What is the minimum order quantity (MOQ)?
Standard MOQ is 1 set. We offer flexible terms for volume orders with competitive pricing for larger projects.
What is the delivery time after order confirmation?
Production typically takes 20-30 days for standard models. We provide precise timelines based on quantity and inventory status upon order confirmation.
What payment terms do you offer?
We commonly accept T/T with 30% deposit and 70% balance before shipment. Other terms like L/C can be discussed for established relationships.
Do you perform factory inspection before shipment?
Yes, every unit undergoes thorough factory testing and inspection before shipment to ensure quality and performance standards.
