8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz

1
MOQ
USD 300-860
preço
8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz
Características Galeria Descrição de produto Peça umas citações
Características
Especificações
Destacar:

8kW diesel generator 3 phase

,

10kVA silent generator set

,

YD380D diesel generator 50Hz
Informação básica
Lugar de origem: China
Marca: YANGDONG
Número do modelo: Yangdong YD380D
Condições de Pagamento e Envio
Detalhes da embalagem: 175*85*103cm
Tempo de entrega: 30 DIAS DE TRABALHO
Termos de pagamento: L/C, T/T, D/P
Habilidade da fonte: 500pcs por mês
Descrição de produto
8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz
YANGDONG Y Diesel Genset. Our YUNNEI YN48ECD120 Diesel Generator is a high-performance, heavy-duty diesel generator set designed for reliable prime and standby power. Engineered with the renowned YANGDONG engine, this 100kW unit is encased in a robust soundproof canopy, making it an ideal solution for applications requiring low noise operation without compromising on power and durability. It is the perfect power source for construction, industrial, commercial, and emergency backup use.
8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz 0
General Specifications
SpecificationPrime PowerStandby Power
Rated Power (kVA)1011
Power Rating (kW)89
Frequency (Hz)50
Engine ModelYD380D
Engine Speed (RPM)1500
Phase3
PF0.8
Control SystemDigital
Rated Voltage (V)400/230 (According to customer requirements)
Fuel Tank Capacity Operating Time≥ 8h @ 75% load
PRP - Prime power is available for an unlimited number of annual hours in variable load application, in accordance with GB/T2820-97; A 10% overload capability is available for a period of 1 hour within a 12-hour of operation.
ESP - The standby power rating is applicable for supplying emergency power for the duration of a utility power interruption. No overload, utility parallel or negotiated outage operation capability is available at this rating.
Dimensions and Weight
ModelBY11 (Open Type)BY11S (Silent Type)
Length (L) mm11501750
Width (W) mm610850
Height (H) mm11001030
Tank Capacity (L)1818
Engine Specifications
Engine Model & ManufacturerYD380D (YANGDONG)
No. of Cylinders3
Injection TypeDirect
ConfigurationVertical
AspirationNatural
Cooling SystemWater-cooled
Bore80 mm
Stroke90 mm
Compression Ratio18
Displacement1.357 L
Dry Engine Weight165 kg
Dimension (L*W*H)587*474*628
The Flywheel Shell InterfaceSAE4
Governed Engine Speed1500
Continuous Power without Fans10
Standby Power11
Adaptive Power Station (kW)13
Alternator Specifications
Alternator BrandBOBIG
Alternator ManufacturerFUJIAN BOBIG ELECTRIC MACHINERY CO.,LTD
Alternator ModelBW-164B
Alternator Rated Power8kw/10kva
Rated Voltage (V)230v/400v
Rated Frequency50hz
Connecting Type3 Phase and 4 W
Number of Bearing1
Protection GradeIP23
Altitude≤1000m
Exciter TypeBrushless, Self-exciting, AVR automatic voltage regulating, 100% Copper
Insulation ClassH class
Telephone Influence Factor (TIF)≤50
THF≤2%
Voltage Regulation, Steady State≤±1%
Transient State Voltage≤-15%～+20%
Control Panel - DSE 6120
Auto start and auto mains failure control module (Alternator frequency & can speed sensing)
Key Benefits
  • Automatically transfers between mains (utility) and generator (DSE6120 MKIII only) for convenience
  • Hours counter provides accurate information for monitoring and maintenance periods
  • User-friendly set-up and button layout for ease of use
  • Multiple parameters are monitored & displayed simultaneously for full visibility
  • The module can be configured to suit a wide range of applications for user flexibility
  • PLC editor allows user configurable functions to meet user specific application requirements
8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz 1
Key Features
  • 4-line back-lit LCD text display
  • Multiple display languages
  • Five-key menu navigation
  • LCD alarm indication
  • Customisable power-up text and screen images
  • DSENet® expansion compatibility
  • Data logging facility
  • Internal PLC editor
  • Protections disable feature
  • Fully configurable via PC using USB communications
  • Front panel configuration with PIN protection
  • Power save mode
  • 3-phase generator sensing and protection
  • 3-phase mains (utility) sensing and protection (DSE6120 MKIII only)
  • Automatic load transfer control (DSE6120 MKIII only)
  • Generator current and power monitoring (kW, kvar, kVA, pf)
  • Mains (utility) current and power monitoring (kW, kvar, kVA, pf) (DSE6120 MKIII only)
  • kW overload alarm
  • Over current protection
  • Breaker control via fascia buttons
  • Fuel and start outputs configurable when using CAN
  • 6 configurable DC outputs
  • 4 configurable analogue/digital inputs
  • Support for 0 V to 10 V & 4 mA to 20 mA sensors
  • 8 configurable digital inputs
  • CAN, MPU and alternator frequency speed sensing in one variant
  • Real time clock
  • Manual and automatic fuel pump control
  • Engine pre-heat and post-heat functions
  • Engine run-time scheduler
  • Engine idle control for starting & stopping
  • Fuel level alarms
  • 3 configurable maintenance alarms
  • Compatible with a wide range of CAN engines, including Tier 4 engine support
  • Uses DSE Configuration Suite PC Software for simplified configuration
  • Licence-free PC software
  • IP65 rating (with optional gasket) offers increased resistance to water ingress
  • Configurable CAN read & transmitted information
  • 1 alternative configuration
Options
EngineAlternatorFuel SystemGenerating Set
Water Jacket PreheaterPMG excitation12 / 24 hour base tankDeepsea, ComAp, Smartgen etc. controller
Oil PreheaterSpace heaterBunded fuel tankTrailer
Oil manual pumpWinding temperature measuringExternal fuel tankTools with the machine
Automatic fuel feeding
Switch between external tank and base tank (three-way valve)
8kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz 28kW 10kVA YANGDONG YD380D Diesel Generator Set 3 Phase 50Hz 3
